Multiple Type Voltage Protecto
  • Volt Protector-S

Product Name:Volt Protector-S

Product Model:


Wechat:dilys15088970667

WhatsApp:008615088970667

JOIN TEH INQUIRY

  • Parameters
  • Features
  • Structure Chart
  • Package
  • Application
  • Video

Technical Data

Voltage Protector
Nominal Voltage230V
Current Rating7A/10A/13A
Frequency50/60Hz
Low Voltage-LVD High SensitivityDisconnect: 185VAC Reconnect:190VAC
Low Voltage-LVD Low SensitivityDisconnect: 175VAC Reconnect:180VAC
High Voltage-LVD High SensitivityDisconnect: 265VAC Reconnect:260VAC
High Voltage-LVD Low SensitivityDisconnect: 255VAC Reconnect:250VAC
Mains Spike Response Time<10ns
Mains Spike Discharge Amps6.5kA
Spike Protection160J
Wait TimeHigh Voltage Protection: 30 Seconds, Low Voltage Protection: 3 minutes.
